The Elite Hydraulic-950 is designed for reliability, security, and simple upkeep, this configuration is environmentally safe. It doesn’t require entry beneath the pit level nor does it need added overhead room for the elevator.
Vibration-Free Submersible Hydraulic Pump Elevators
Florida Elevators takes pride installing vibration-free submersible hydraulic pumping units. In regard to a hydraulic application, the pumping unit is located in a space outside of the elevator hoistway, such as a dedicated machine room, in a closet, under stairs or in a garage.
Locating the pumping unit outside the elevator hoistway makes for simple and safe access during scheduled maintenance along with eliminating the disturbance from any machine noise within the elevator car, which can be found with other models.
Roped hydraulic home elevators are equipped with two 3/8″ diameter hoist ropes and an instantaneous cabin safety that’s triggered by decreasing rope slack in any single hoist system. Florida Elevators secures door interlocks on all existing hall doors so that the hall door can’t be ajar if the elevator isn’t stable stopped at a floor.
- Travel up to 50’
- Up to six (6) stops
- Load capacity: 950 (standard, 1400lbs optional)
- Speed: 40 FPM
- Overhead: 8’-0” minimum (7’-0” cab height)
- Pit depth: 8” minimum (12” recommended)
- Smooth Roped Hydraulic Drive
- 1:2 roped hydraulic
- Remote machine room can be located up to 35 feet from ground floor
- 3 HP submersed motor with 2-speed hydraulic valve for quiet operation
- 220 volt single phase power supply
- LED lighting
Wide Range of Features
Fits Tight Spaces
With the minimum overhead of only 7’-8” and a minimum pit depth of 8” (12” recommended), Florida Elevator’s hydraulic units can be placed in some of the most hard to fit spots.
Quiet & Smooth Ride
Florida Elevator’s Roped Hydraulic Home Elevators is South Florida’s most in-demand design due to it’s quiet and smooth ride.
All lighting in our elevators are of energy-efficient LED technology. We provide a well-lit, cabin, while keeping energy costs in mind.
Safety is a Priority at Florida Elevators
Safety is a priority at Florida Elevators. Roped hydraulic home elevators are equipped with two 3/8″ diameter hoist ropes and an instantaneous cabin safety that’s triggered by decreasing rope slack in any single hoist system. Florida Elevators secures door interlocks on all existing hall doors so that the hall door can’t be ajar if the elevator isn’t stable stopped at a floor.
A Pit Float Switch is installed as a standard feature in our home elevators. For homes at or below sea-level this is important. A Pit Float Switch is activated by water. When this happens the pit float switch will deliver the elevator to the nearest floor above flood elevation.
If there is a power outage, all elevator models at Florida Elevators have a integrated emergency lowering system which allow the cabin to carefully descend to a lower level. In accordance with the American Standard of Mechanical Engineers (ASME A17.1) Safety Code for Elevators, all of our safety devices are tested and certified.
